OWON 12A / 6A Dual Output Programmable DC Power Supply
- Two independent controllable channels+Sense
- Output resolution : 1mV / 1mA
- Low ripples / low noise
- Up to 100 group timers
- Multi- working mode : individual, parallel, and series
- Over-voltage / Over-current protection
- Data-logging function: could record the output voltage, and current;
and display recorded data in chart
- Auto-cooling system
- 4 inch high resolution (480 × 320 pixels) LCD
- Multi- CI: USB, RS232, and LAN
- SCPI, and LabVIEW supported
E-mail UsSupport
Product Details
1. Creative Data Recording Function
to monitor the changing status of powering system, displaying recorded data in chart. E Low Ripples / Low Noise
2. Timing Output
Support 100 groups timing output settings, the power output curve could be adjusted via PC,
or device itself. And applicable to artificial simulated power output variation.
3. Low Ripples / Low Noise
OWON ODP features super- low ripples, and super- low noise,
which causes almost no influences to circuit test.
Specifications
| Model | ODP3122 | ODP6062 | ||||||
|---|---|---|---|---|---|---|---|---|
| Channel | 2 independent controllable channels+Sense | |||||||
| Max Output Power | 378W | |||||||
| Output Range | 0 - 30V / 12A 1CH, 0 - 6V / 3A 1CH |
0 - 60V / 6A 1CH, 0 - 6V / 3A 1CH |
||||||
| Display | ||||||||
| LCD Type | 4 inch colored LCD | |||||||
| Display Resolution | 480 x 320 pixels, 65536 colors | |||||||
| Mechanical Specifications | ||||||||
| Dimension (W x H x D) | 250 x 158 x 358 (mm) | |||||||
| Device Weight | 12.00 kg | |||||||
The specifications based upon the instrument having run for at least 30 minutes continuously, under the specified operating environment
| Model | ODP3122 | ODP6062 | ||||||
|---|---|---|---|---|---|---|---|---|
| Channel | CH1 | CH2 | CH1 | CH2 | ||||
| Output Ratings （0℃-40℃） |
Voltage | 0 - 30V | 0 - 6V | 0 - 60V | 0 - 6V | |||
| Current | 0 - 12A | 0 - 3A | 0 - 6A | 0 - 3A | ||||
| Load Regulation | Voltage | ≤0.01% + 3mV | ||||||
| Current | ≤0.01% + 3mA | |||||||
| Line Regulation | Voltage | ≤0.01% + 3mV | ||||||
| Current | ≤0.01% + 3mA | |||||||
| Settings Resolution | Voltage | 1mV | ||||||
| Current | 1mA | |||||||
| Read Back Resolution | Voltage | 1mV | ||||||
| Current | 1mA | |||||||
| Settings Accuracy (25℃ ± 5℃) (within 12 months) |
Voltage | ≤0.03% + 10mV | ||||||
| Current | ≤0.1% + 8mA | ≤0.1% + 5mA | ||||||
| Read Back Accuracy (25℃ ± 5℃) |
Voltage | ≤0.03% + 10mV | ||||||
| Current | ≤0.1% + 8mA | ≤0.1% + 5mA | ||||||
| Noise and Ripple (20Hz - 20MHz) |
Voltage (Vp-p) | ≤4mVp-p | ≤3mVp-p | |||||
| Voltage (rms) | ≤1mVrms | ≤1mVrms | ||||||
| Current (rms) | ≤5mArms | ≤4mArms | ||||||
| Output Temperature Coefficient (0℃ - 40℃) |
Voltage | ≤0.03% + 10mV | ||||||
| Current | ≤0.1% + 5mA | |||||||
| Read Back Temperature Coefficient | Voltage | ≤0.03% + 10mV | ||||||
| Current | ≤0.1% + 5mA | |||||||
| Parallel Settings Accuracy | Voltage | ≤0.02% + 5mV | ||||||
| Current | ≤0.1% + 30mA | |||||||
| Programmable Output | Storage | 100 groups | ||||||
| Time Setting | second | |||||||
| Data Recording | 10 K groups (of voltage, current and power data) recording capacity | |||||||
| Working Temperature | 0 - 40℃ | |||||||
| Communication Interface | USB Host&Divice, RS232, and LAN | |||||||
Accessories
The accessories subject to final delivery.
-
Power Cord -
CD Rom -
Quick Guide -
USB Cable -
Fuse -
Test Leads (optional)
