Model

SP3051

SP3101

SP6101

SP6053

SP3103

SP6103

Channel

Single Channel Output

Total Output Power

150W

300W

Channel Output

0 - 30V / 0 - 5A

0 - 30V / 0 - 10A

0 - 60V / 0 - 10A

0 - 60V / 0 - 5A

0 - 30V / 0 - 10A

0 - 60V / 0 - 10A

Display

4 inch color LCD display

Dimension

117mm(L)*194mm（H）*295mm（D）

Weight

Approx. 3.0kg

Interface

RS232

Model

SP3051

SP3101

SP6101

SP6053

SP3103

SP6103

Rated Output

 (0℃-40℃)

Voltage

0 - 30V

0 - 30V

0 -60V

0 -60V

0 - 30V

0 -60V

Current

5A

10A

10A

5A

10A

10A

Output Power

150W

150W

150W

300W

300W

300W

Load Regulation

Voltage

≤30mV

Current

≤30mA

Power Regulation

Voltage

≤20mV

Current

≤20mA

Setting Resolution

Voltage

10mV

Current

1mA

Readback Resolution

Voltage

10mV

Current

1mA

Value Resolution

(within 12 months)

(25℃±5℃)

Voltage

≤0.1% ± 20mV

≤0.1% ± 30mV

≤0.1% ± 20mV

≤0.1% ± 30mV

Current

≤0.05% ± 10mA

Readback Value Resolution

(25℃±5℃)

Voltage

≤0.1% ± 20mV

≤0.1% ± 30mV

≤0.1% ± 20mV

≤0.1% ± 30mV

Current

≤0.1% ± 10mA

Ripple/Noise

(20Hz-20MHz，measured with external 10μF + 100nF capacitor)

Voltage (Vp-p)

≤30mVp-p

≤50mVp-p

≤30mVp-p

≤50mVp-p

Voltage (rms)

≤3mVrms

≤5mVrms

≤3mVrms

≤5mVrms

Current (rms)

≤30mAp-p

Output temperature coefficient

(0℃-40℃)

Voltage

≤0.3% ± 10mV

≤0.3% ± 20mV

≤0.3% ± 10mV

≤0.3% ± 20mV

Current

≤0.3% ± 10mA

≤0.3% ± 20mA

Readback temperature coefficient

Voltage

≤0.3% ± 10mV

≤0.3% ± 20mV

≤0.3% ± 10mV

≤0.3% ± 20mV

Current

≤0.3% ± 10mA

≤0.3% ± 20mA

Response Time

≤1.0ms

Storage

5 groups of data

Working Temperature

0-40℃
